Tomahawk 8200 series
The 8200 Bale Processor - Designed for your Feeding and Bedding
The 8200 feeder bedder, which replaces the 7100 and 8100 models, now features a significantly larger diameter crossbeater for increased processing speed.
Key Benefits:
Variable position bale restraint (adjusted via WIFI control) ensures optimum output with straw, hay or silage.
Manufactured using Hardox, the wearing surfaces in the chute offer a service life up to 3 times longer than standard steel.
Manufactured using Hardox, the wearing surfaces in the chute offer a service life up to 3 times longer than standard steel.
For operators familiar with the previous 7100 and 8100 models, a fixed bale restraint is available as an option.
For operators familiar with the previous 7100 and 8100 models, a fixed bale restraint is available as an option.
The 8200T is also available as the 8200M 'Mounted' model.
The 8200T is also available as the 8200M 'Mounted' model.
Our latest large diameter crossbeater design handles all materials, with 54 blades to provide an even feed rate.
Our latest large diameter crossbeater design handles all materials, with 54 blades to provide an even feed rate.
The tethered WiFi control desk has been updated to include the new 'SYNCHRO' functions to get the most from the Dual Chop system. Maximum output, minimum effort.
The tethered WiFi control desk has been updated to include the new 'SYNCHRO' functions to get the most from the Dual Chop system. Maximum output, minimum effort.
Our 2 speed fan has an updated paddle design to ensure a consistent delivery and maximum blow distance. The 8 paddles are easily replaced for straightforward servicing.
The bale retention beam on the tailgate can be adjusted between one loading and six operating positions.
Seven heavy-duty 60mm x 40mm bed slats are attached with U-Bolts for straightforward servicing to large 10mm diameter galvanised bed chains.
For reliable transmission of power the 8250 crossbeater has a heavy duty chain drive that is automatically lubricated when the bed chain is running.
The 8200 series is designed with high sides to contain material, with horizontal surfaces also eliminated to keep the machine clean.
The PTO is fitted with overrun and Slip Clutch driveline protection.
Essential for highway use, the front and rear markers ensure that you operate safely when travelling on the road. (standard on trailed models).
All Tomahawk models feature a high specification gearbox, with high/low fan speed gear preselection.
Stones and debris can quickly be removed from the drop down hatch at the rear of the machine.
For flexibility of delivery, the chute rotates 280 degrees allowing material to be directed to where it is needed. An adjustable feed slide is fitted for accurate placement of feed materials.
Load bales without having to return to the tractor cab, ideal when removing netting or wrap.
Auto chain oiler (crossbeater drive) is recommended for high-use operations.
The 8200T is also available with a fixed bale restraint and no mudguards (UK only).
Ring or K80 hitches can be specified.
Reduce respirable dust by up to 40% with our Hydroshield water spray system. An onboard tank and 5 high pressure spray nozzles.
In-line high pressure filter prevents contamination from damaging the valve equipment.
The optional ‘Ski Jump Chute’ is perfect for bedding pig arcs and mulching fruit trees. As standard it is fitted with hydraulic control of the angle (requires second spool).
For non-stop bedding when maneuvering around yards, select the Wide Angle PTO option.
Auto chain oiler (crossbeater drive) is recommended for high-use operations.
Reduce respirable dust by up to 40% with our Hydroshield water spray system. An onboard tank and 5 high pressure spray nozzles.
In-line high pressure filter prevents contamination from damaging the hydraulic valve.
The optional ‘Ski Jump Chute’ is perfect for bedding pig arcs and mulching fruit trees. As standard it is fitted with hydraulic control of the angle (requires second spool).
For non-stop bedding when manoeuvering around yards, select the Wide Angle PTO option.
The tethered WiFi control desk has been updated to include the new 'SYNCHRO' functions to get the most from the Dual Chop system. Maximum output, minimum effort.
Ring or K80 hitches can be specified.
The 8200T is also available with a fixed bale restraint and no mudguards (UK only).
All Teagle products are now treated with a double powder coat paint finish; our latest upgrade in product quality and durability.
British Built. Making an impression worldwide!
Built in Britain. Making an impression worldwide!
For a longer service life and improved residual value, we have made a significant investment in a new double powder coat paint line facility, commissioned in 2023.
All of our trailed implements are manufactured in accordance with In Homologation certification according Article 35 of Regulation (EU) No. 167/2013.
All of our trailed implements are manufactured in accordance with In Homologation certification according Article 35 of Regulation (EU) No. 167/2013.
Owners and operators report up to 30% straw savings compared to manual bedding, as well as a significant time saving by pre-processing the straw element of a TMR ration.
Owners and operators report up to 30% straw savings compared to manual bedding, as well as a significant time saving by pre-processing the straw element of a TMR ration.
Our 2 speed fan has an updated paddle design to ensure a consistent delivery and maximum blow distance. The 8 paddles are easily replaced for straightforward servicing.
The bale retention beam on the tailgate can be adjusted between one loading and six operating positions.
Seven heavy-duty 60mm x 40mm bed slats are attached with U-Bolts for straightforward servicing to large 10mm diameter galvanised bed chains.
For reliable transmission of power the 8250 crossbeater has a heavy duty chain drive that is automatically lubricated when the bed chain is running.
The 8200 series is designed with high sides to contain material, with horizontal surfaces also eliminated to keep the machine clean.
The PTO is fitted with overrun and Slip Clutch driveline protection.
Essential for highway use, the front and rear markers ensure that you operate safely when travelling on the road. (standard on trailed models).
All Tomahawk models feature a high specification gearbox, with high/low fan speed gear preselection.
Stones and debris can quickly be removed from the drop down hatch at the rear of the machine.
For flexibility of delivery, the chute rotates 280 degrees allowing material to be directed to where it is needed. An adjustable feed slide is fitted for accurate placement of feed materials.
Load bales without having to return to the tractor cab, ideal when removing netting or wrap.
Auto chain oiler (crossbeater drive) is recommended for high-use operations.
The 8200T is also available with a fixed bale restraint and no mudguards (UK only).
Ring or K80 hitches can be specified.
Reduce respirable dust by up to 40% with our Hydroshield water spray system. An onboard tank and 5 high pressure spray nozzles.
In-line high pressure filter prevents contamination from damaging the valve equipment.
The optional ‘Ski Jump Chute’ is perfect for bedding pig arcs and mulching fruit trees. As standard it is fitted with hydraulic control of the angle (requires second spool).
For non-stop bedding when maneuvering around yards, select the Wide Angle PTO option.
Auto chain oiler (crossbeater drive) is recommended for high-use operations.
Reduce respirable dust by up to 40% with our Hydroshield water spray system. An onboard tank and 5 high pressure spray nozzles.
In-line high pressure filter prevents contamination from damaging the hydraulic valve.
The optional ‘Ski Jump Chute’ is perfect for bedding pig arcs and mulching fruit trees. As standard it is fitted with hydraulic control of the angle (requires second spool).
For non-stop bedding when manoeuvering around yards, select the Wide Angle PTO option.
The tethered WiFi control desk has been updated to include the new 'SYNCHRO' functions to get the most from the Dual Chop system. Maximum output, minimum effort.
Ring or K80 hitches can be specified.
The 8200T is also available with a fixed bale restraint and no mudguards (UK only).
All Teagle products are now treated with a double powder coat paint finish; our latest upgrade in product quality and durability.
British Built. Making an impression worldwide!
Built in Britain. Making an impression worldwide!
For a longer service life and improved residual value, we have made a significant investment in a new double powder coat paint line facility, commissioned in 2023.
All of our trailed implements are manufactured in accordance with In Homologation certification according Article 35 of Regulation (EU) No. 167/2013.
All of our trailed implements are manufactured in accordance with In Homologation certification according Article 35 of Regulation (EU) No. 167/2013.
Owners and operators report up to 30% straw savings compared to manual bedding, as well as a significant time saving by pre-processing the straw element of a TMR ration.
Owners and operators report up to 30% straw savings compared to manual bedding, as well as a significant time saving by pre-processing the straw element of a TMR ration.
Matt Annear at Tregair Farm nr. Newquay, Cornwall
"There are some great features on the new machine and it makes the jobs of bedding and feeding easier. We save at least half an hour each time by bedding with the Teagle compared to our usual bale processor.
The silage is chopped well and now the cattle eat all of the feed and there is no waste, they even look healthier and happier. We have only had the machine 4 months, but we can already see the daily gains.
Central greasing makes maintenance of the machine straightforward and easy, then the mudguards keep the machine clean.
Description | 8200T |
Chute | Swivel |
Dual Chop | No |
Silage | Yes |
Straw | Spread |
Crossbeaters | 1 |
Capacity (m3) | 3.2 |
No. of 5’ round bale | 2 |
No. of 8’ rect' bales (4’x 2’6”/ 4’x4’) | 1/1 |
Bale chamber (tailgate down) W x H x L | 1.43 x 1.35 x 3.00m |
Blow distance (max.) | 20m |
Tractor power (min.) | 60HP / 45kW |
PTO speed | 1,000 rpm |
Overall width (chute closed) | 2.03m |
Overall length (tailgate up) | 4.12m |
Overall length (tailgate/bale clamp down) | 5.98m |
Overall height (chute closed) | 2.57m |
Unladen weight | 2,213kg |
Tyre size | 10.00/75-15.3 |
Oil flow rate (min/max) (l/min) | 35 - 60 |
